Quick Answer
Every Sony UP-895, UP-897 and UP-898 Series ultrasound printer takes the same 110mm thermal paper family. That means a mixed fleet of UP-895MD, UP-D897 and UP-D898MD units can run one roll — and Durico makes a drop-in compatible grade for each Sony type: Sony UPP-110S compatible standard paper (Durico 1100S), Sony UPP-110HD compatible high-density paper (Durico 1100HD) and Sony UPP-110HG compatible high-gloss paper (Durico 1100HG). Pick the grade your most demanding workflow needs, and the whole fleet can share it.
Why Mixed Sony Fleets End Up Stocking Three Papers
Very few imaging departments bought their printers in one order. A typical room-by-room inventory looks like this: a UP-895MD that came bundled with a scanner in 2012, a UP-D897 that replaced a failed unit a few years later, and a UP-D898MD or UP-X898MD on the newest cart. Each printer was purchased with a starter box of paper, each box had a different Sony part number on it, and each part number quietly became its own line on the supply order.
Multiply that by a few sites and a practice can carry five or six paper SKUs for what is, mechanically, one paper. Every extra SKU is a separate reorder point, a separate chance of a stockout, and a separate opportunity to load the wrong grade into a printer whose menu is set for a different one. The fix is a fleet standardization: one paper, one part number, one par level. This guide covers which Sony printers can share a roll, which cannot, how to choose the grade, and how to roll it out.
Which Sony Printers Share the Same Paper
Sony's UP-895, UP-897 and UP-898 Series are all 110mm (A6-width) black-and-white thermal printers, and Sony specifies the same three paper types across the family: UPP-110S (Type I, standard), UPP-110HD (Type II, high-density) and UPP-110HG (Type V, high-gloss). Durico's compatibility chart lists each of its 110mm ULSTAR grades against exactly those three series. The table below is the entire single-roll fleet.
| Sony printer series | Models in the series | Sony OEM paper | Durico compatible grade | Roll spec |
|---|---|---|---|---|
| UP-895 Series | UP-895MD, UP-D895 | UPP-110S / UPP-110HD / UPP-110HG | Sony UPP-110S compatible Durico 1100S · Sony UPP-110HD compatible Durico 1100HD · Sony UPP-110HG compatible Durico 1100HG | 110mm × 20m (S, HD) · 110mm × 18m (HG) |
| UP-897 Series | UP-897MD, UP-D897 | UPP-110S / UPP-110HD / UPP-110HG | Same three grades | Same |
| UP-898 Series | UP-D898MD, UP-X898MD, UP-D898DC | UPP-110S / UPP-110HD / UPP-110HG | Same three grades | Same |
Two details before you standardize. First, the letters in the model number describe the printer's inputs and power, not its paper: the D in UP-D898MD means digital (USB) input, the X in UP-X898MD adds analogue video input, and the DC in UP-D898DC means it runs from the host system's DC supply. All three take the same media. The full breakdown is in Sony ultrasound printer model numbers decoded. Second, whether the UP-D897MD and UP-D898MD really share paper is answered in Sony UP-D897MD vs UP-D898MD: do they use the same paper? (they do).
What Does Not Fit the Single-Roll Plan
Check the fleet list against these three groups before placing a consolidated order.
Large-format printers: UP-970AD, UP-971AD, UP-990AD and UP-991AD. These are 210mm (A4-width) printers and take Sony UPP-210HD. They cannot share a 110mm roll, but they do have their own Durico equivalent, the Sony UPP-210HD compatible Durico 2100HD (210mm × 25m). A fleet with both widths standardizes on two SKUs, not one, and that is still a large reduction from where most departments start.
The 84mm UP-D711MD. This compact printer takes 84mm (A7-width) media — Sony UPP-84S or UPP-84HG. Durico documents an 840S and 840HG for it, but Precision Imaging Supply does not currently stock the 84mm line, so a UP-D711MD stays on its own supply chain for now. The width families are compared in Ultrasound paper widths explained: 84mm vs 110mm vs 210mm.
Legacy 850/860/870/890-series units. Durico's documented compatibility for the 110mm grades is the UP-895, UP-897 and UP-898 Series, full stop. Older Sony printers such as the UP-D890, UP-860MD or UP-850MD are outside that documented range. That does not mean they will not run the paper — it means nobody has certified it. If you have one still in service, follow the verify-fit checklist in Your legacy Sony ultrasound printer's paper is discontinued — what are your options? before folding it into the standard order.
Choosing the One Grade the Whole Fleet Will Run
Because every 895/897/898-series printer accepts all three Sony paper types, the standardization decision is really a grade decision. Durico defines its three 110mm grades the same way Sony does:
- Standard (1100S, UPP-110S equivalent) — matte finish, the most economical type. The default for routine OB/GYN, general imaging and veterinary scanning where the print goes into a chart or is handed to a patient and filed.
- High-Density (1100HD, UPP-110HD equivalent) — semi-glossy surface built for precise gradation of grey-scale. The usual choice where prints are read for detail rather than kept as mementos.
- High-Gloss (1100HG, UPP-110HG equivalent) — the most glossy surface, with the photorealistic reproduction that keepsake and 3D/4D studios want.
The rule that keeps a standardization from unravelling is simple: standardize on the grade your most demanding workflow needs, not the cheapest one. If one room prints keepsake images and the other four print chart copies, standardizing on Standard will save money on four printers and generate complaints from the fifth — and within a month someone will quietly reorder gloss for that room and you are back to two SKUs. Either standardize on the higher grade fleet-wide, or make a deliberate two-SKU decision (Standard for clinical rooms, High-Gloss for the keepsake room) and write it down.
All clinical documentation: Standard. Prints reviewed for grey-scale detail: High-Density. Any room that sells or gifts prints: High-Gloss. The grade comparison in Sony UPP-110HG vs UPP-110HD vs UPP-110S: which paper do you actually need? goes deeper on each surface.
Mind the roll length when you set par levels
One spec that changes with the grade: Durico 1100S and 1100HD are 110mm × 20m rolls, while 1100HG is 110mm × 18m — the same lengths as the corresponding Sony types. A fleet moving from Standard to High-Gloss gets 10% less paper per roll, so the reorder quantity has to rise to match. Nothing else about the roll changes; only the par-level spreadsheet does.
Why a Compatible Grade Behaves Identically Across the Fleet
A standardization is only as good as the paper's consistency from printer to printer, and that comes down to construction. Every Durico ULSTAR 110mm grade is built on the same five-layer stack — a polypropylene film substrate, a UV-cured glossy layer, a protective layer, the thermal coat and a back-coat — with a built-in anti-electrostatic layer that Durico specifies for protecting the thermal head. Durico manufactures the paper itself in South Korea, is FDA Registered, and holds ISO 9001, ISO 14001 and ISO 13485 certification. The layer-by-layer detail is in What's inside ultrasound thermal paper? The 5-layer construction.
Because each grade is engineered to the matching Sony paper Type — 1100S to Type I, 1100HD to Type II, 1100HG to Type V — a UP-895MD in one room and a UP-D898MD in the next are calibrating for the same media when you set their paper-type menu to that grade. That is the mechanism that makes "one roll, many printers" work: the printer's density and gamma tables are keyed to the paper Type, not to the brand printed on the box.
The Rollout: Five Steps to a One-Paper Fleet
- Inventory every printer by full model number. Walk the rooms and carts, and record the exact model from the label on the printer, not from memory. Sort the list into three buckets: UP-895/897/898 Series (single 110mm roll), UP-970/971/990/991AD (210mm roll), and anything else (verify separately).
- Pick the fleet grade using the most-demanding-workflow rule above, and note whether any room needs a documented exception.
- Pilot one box on the busiest printer. Load the new grade, then set the printer's paper-type menu to match it — on the UP-D898MD that is the PP.TYPE setting, with HG, HD and S as the options. A printer left on a different paper type than the one loaded will print too dark or too light, and that is a settings problem, not a paper problem. The full menu walk-through is in Sony UP-D898MD prints too dark or too light? Contrast, brightness and paper-type settings explained.
- Update the purchase order and par levels. Replace the three (or six) OEM part numbers with one Durico part number. Recalculate the reorder quantity from roll length and combined fleet usage.
- Run the old stock down, room by room. Do not throw away good OEM paper; finish it, and switch each printer's paper-type menu at the moment its last OEM roll comes out. Note the switch date per printer so any later print-quality question can be traced to a settings change.
What Standardizing Actually Saves
The direct saving is the per-roll difference between Sony OEM media (OEM meaning original equipment manufacturer — Sony-branded paper) and the compatible grade. Current Precision Imaging Supply pricing at the time of writing:
| Durico grade | Sony equivalent | 5-roll box | 10-roll box |
|---|---|---|---|
| Sony UPP-110S compatible Durico 1100S | UPP-110S | $43.95 | $82.95 |
| Sony UPP-110HD compatible Durico 1100HD | UPP-110HD | $64.95 | $129.95 |
| Sony UPP-110HG compatible Durico 1100HG | UPP-110HG | $64.95 | $129.95 |
Sony OEM 110mm media from medical resellers is priced across a wide band — roughly $70–$105 per 10-roll case for UPP-110S and roughly $125–$160 for UPP-110HG at the time of writing, depending on the reseller and quantity. Durico's own literature puts the savings against competing products at 25–30%; because the OEM band is wide, the honest advice is to price your chosen grade both ways before you switch.
The indirect savings are the point of standardizing: one reorder point instead of several, no room running out while another holds a surplus of the wrong grade, and — for multi-site groups — the ability to move a case between locations knowing it fits every printer. Larger groups planning a consolidated order will find the volume approach in Bulk ultrasound paper for imaging centers: pricing and stock strategy.
Frequently Asked Questions
Can a Sony UP-895MD, UP-D897 and UP-D898MD really all use the same roll?
Yes. Sony's UP-895, UP-897 and UP-898 Series are all 110mm printers specified for the same UPP-110S, UPP-110HD and UPP-110HG paper types, and Durico lists its 1100S, 1100HD and 1100HG grades as compatible with all three series. One roll of any of those grades fits every printer in the family.
Do the UP-X898MD and UP-D898DC take the same paper as the UP-D898MD?
Yes. The X and DC designations describe the printer's inputs and power supply, not its media. All three are UP-898 Series printers and take the same 110mm paper.
Can I include my UP-990AD or UP-991AD in the same standard?
Not on the same roll — those are 210mm printers and take UPP-210HD. They can still be standardized on a single compatible SKU of their own, the Durico 2100HD, giving a two-width fleet exactly two paper part numbers.
Which grade should a mixed fleet standardize on?
The grade the most demanding room needs. Standard for all-clinical documentation, High-Density where grey-scale detail is reviewed, High-Gloss if any room hands out keepsake prints. Standardizing on the cheapest grade when one room needs gloss usually ends with two SKUs anyway.
Do I have to change any printer settings when I switch?
Only the paper-type menu, and only if the new grade differs from the one the printer was set for. Set each printer's paper type (PP.TYPE on the UP-D898MD) to match the grade loaded, then leave contrast and brightness where they were unless prints look wrong.
What about my older UP-D890 or UP-860MD?
Those are outside Durico's documented compatibility range, which covers the UP-895, UP-897 and UP-898 Series for 110mm paper. Verify fit on a single roll before adding a legacy printer to the standard order; the legacy-printer guide linked above explains how.
Will running compatible paper across the fleet void the Sony warranty?
Under US law a manufacturer generally cannot void a warranty simply because a third-party consumable was used, though it can decline to cover damage actually caused by that consumable. Commercial purchases may fall outside consumer-warranty statutes, so read the details in Does compatible paper void your Sony ultrasound printer warranty?.
Standardize the Fleet on One Roll
If your printers are all UP-895, UP-897 or UP-898 Series, you can consolidate today. Start with the grade that fits your most demanding room:
- Sony UPP-110S compatible standard paper — Durico 1100S, 110mm × 20m (also available as a 10-roll box)
- Sony UPP-110HD compatible high-density paper — Durico 1100HD, 110mm × 20m (also available as a 10-roll box)
- Sony UPP-110HG compatible high-gloss paper — Durico 1100HG, 110mm × 18m (also available as a 10-roll box)
Not sure which bucket a printer falls into? The full Sony ultrasound printer compatibility index lists every model and its matching grade.
